853 S8 | Mining Scaler


853 S8

Model

853 S8

Approximate vertical reach

up to 26' 3"

up to 8,000 mm

Length

24' 11"

7,600 mm

Find a Dealer

Additional Images:


Operating Weight (base vehicle) 19,300 lbs 8,750 kg
Hammer Size GH 2 - 500 ft lbs GH2 - 678 Nm
Pick optional
Boom Swing +/- 45 degrees
Carrier Articulation +/- 40 degrees
Blade Width 7' 9" 2,350 mm
Low Profile optional
Remote Control optional
Engine Performance Rating 125 hp 93 kW
Speed up to 12.5 mph up to 20 km/h
Gradeability 45%
Braking SAHR, oil immersed
Drive hydrostatic
Tire Size 9.00 R20
Height 8' 1" 2,470 mm
Width 6' 3" 1,900 mm
Wheelbase 8' 2,430 mm
Ground Clearance 11" 270 mm
Turning Radius (inside) 7' 9" 2,350 mm
