C3D


C3D

Model

C3D

Recommended Carrier Weight

3.5 - 9 US tons

3.2 - 8.2 metric tons

Working Weight

fixed: 760 lbs swivel: 800 lbs

fixed: 345 kg swivel: 363 kg

Find a Dealer

Additional Images:


Impulse Force 6,500 ft lbs
Cycles per Minute 2,200 rpm
Oil Flow 19 gpm 72 lmp
Operating Pressure 1,950 - 2,200 psi 134 - 152 bar
Relief Pressure setting 2,600 psi 179 bar
Swivel Feature optional
Baseplate Dimensions 17 x 28 in 430 x 710 mm
Compaction Area 3.3 sq ft 0.3 sq m
Height 29 in 735 mm
Width 17 in 430 mm

Description

Description

Compactor pre-delivery inspection Compactor inspection
Priory to all deliveries, ensure the following items have been verified for each unit.
Check / set compactor manifold relief  Relief setting instructions
If the compactor relief cartridge has been replaced, disturbed, or is suspected to be out of adjustment, the following procedure can be used to check and set the relief.
