C8C


C8C

Model

C8C

Recommended Carrier Weight

15 - 32.5 US tons

13.6 - 29.5 metric tons

Working Weight

fixed: 2,240 lbs swivel: 2,325 lbs

fixed: 1,016 lkg swivel: 1,055 kg

Find a Dealer

Additional Images:


Impulse Force 24,000 ft lbs
Cycles per Minute 2,200 rpm
Oil Flow 43 gpm 163 lpm
Operating Pressure 2,000 - 2,500 psi 138 - 172 bar
Relief Pressure setting 2,600 psi 179 bar
Swivel Feature optional
Baseplate Dimensions 34 x 46 in 865 - 1,170 mm
Compaction Area 10.9 sq ft 1.0 sq m
Height 45 in 1,145 mm
Width 34 in 865 mm

Description

Description

Compactor pre-delivery inspection Compactor inspection
Priory to all deliveries, ensure the following items have been verified for each unit.
Check / set compactor manifold relief  Relief setting instructions
If the compactor relief cartridge has been replaced, disturbed, or is suspected to be out of adjustment, the following procedure can be used to check and set the relief.
