Working Weight

5,650 lbs

2,565 kg

Recommended Carrier Weight

28 - 43 US tons

25.4 - 39 metric tons



Visit and subscribe to NPK's YouTube channel for hydraulic hammer operation and service videos and videos of hydraulic breakers in action!

Visit NPK's photo website for searchable hydraulic hammer photo galleries!

Visit the Hydraulic Hammer Publications page for sales brochures, operators manuals, and service bulletins.  If you require a service manual or would like a hard copy of any other manual, please contact the Sales Department at 440-232-7900 or email to sales@npkce.com.


Visita y suscríbete al canal de YouTube de NPK para videos de instrucciones de servicio para martillos hidráulicos.

NPK offers a wide variety of accessories for hydraulic hammers:

  • Tools
  • Autolube Systems
  • Dust Suppression Kits
  • Grease
  • Quick Disconnects


For more about all types of hammer accessories, visit the Hammer Accessories Page.

Visit the Hammer Accessory Publications page for related
sales brochures, operators manuals and sales bulletins.


Find a Dealer

Additional Images:

Impact Energy Class 5,500 ft lbs
Impact Frequency 400 - 500 bpm
Oil Flow 45 - 58 gpm 170 - 220 lpm
Operating Pressure 2,500 psi 172 bar
Tool Diameter 5.7 in 146 mm
Tool Working Length 25.5 in 650 mm
