Impact Energy Class

750 ft lbs

Working Weight

570 lbs

260 kg


Visit NPK's photo website for searchable photo galleries organized by model!

Click to download the Pneumatic Hammer Operators Manual!


If you require a hard copy of the operators manual, please contact the Sales department at 440-232-7900 or by email at



Find a Dealer

Additional Images:

Recommended Carrier Weight 6 - 9 US tons 5.4 - 8.2 metric tons
Impact Frequency 530 bpm
Air Pressure 85 psi
Air Consumption 5 cu m/min
Compressor 50PS class
Length (without chisel) 47.3 in 1,200 mm
Bore 4.5 in 115 mm
Stroke 7.8 in 200 mm
Hose size 1 in 25 mm
