1253 S10 | Mining Scaler


1253 S10

Model

1253 S10

Approximate vertical reach

up to 32' 10"

up to 10,000 mm

Length

29' 8"

9,050 mm

Find a Dealer

Additional Images:


Operating Weight (base vehicle) 27,500 lbs 12,500 kg
Hammer Size GH2 - 500 ft lbs GH2 - 678 Nm
Pick optional
Boom Swing +/- 45 degrees
Carrier Articulation +/- 40 degrees
Blade Width 8' 4" 2,530 mm
Low Profile optional
Remote Control optional
Engine Performance Rating 131 hp 98 kW
Speed up to 12.5 mph up to 20 km/h
Gradeability 45%
Braking SAHR, oil immersed
Drive hydrostatic
Tire Size 15.5 R25
Height 9' 1" 2,770 mm
Width 7' 7" 2,300 mm
Wheelbase 8' 11" 2,730 mm
Ground Clearance 1' 4" 400 mm
Turning Radius (inside) 8' 4" 2,530 mm
