E220


E220

Model

E220

Working Weight

6,800 lbs

3,085 kg

Recommended Carrier Weight

33 - 50 US tons

30 - 45.4 metric tons






Visit and subscribe to NPK's YouTube channel for hydraulic hammer operation and service videos and videos of hydraulic breakers in action!

Visit NPK's photo website for searchable hydraulic hammer photo galleries!

Visit the Hydraulic Hammer Publications page for sales brochures, operators manuals, and service bulletins.  If you require a service manual or would like a hard copy of any other manual, please contact the Sales Department at 440-232-7900 or email to sales@npkce.com.




Visita y suscríbete al canal de YouTube de NPK para videos de instrucciones de servicio para martillos hidráulicos.


NPK offers a wide variety of accessories for hydraulic hammers:

  • Tools
  • Autolube Systems
  • Dust Suppression Kits
  • Grease
  • Quick Disconnects



For more about all types of hammer accessories, visit the Hammer Accessories Page.


Visit the Hammer Accessory Publications page for related
sales brochures, operators manuals and sales bulletins.




Find a Dealer

Additional Images:


Impact Energy Class 8,000 ft lbs
Impact Frequency 350 - 430 bpm
Oil Flow 53 - 66 gpm 200 - 250 lpm
Operating Pressure 2,350 psi 162 bar
Tool Diameter 6.1 in 156 mm
Tool Working Length 27 in 685 mm

Description
